LED High Bay – MHB16

LED High Bay – MHB16

Short Description:

A cost-effective UFo High Bay that fit within your budget, excelling in both performance and aesthetics, while offering strong adaptability to various environ-ments with its exquisite profile. This compact and lightweight fixture is designed for exceptional durabili ty and practicality, capable of replacing a 1000W MH. The Beam Angle Field-Adjustable MHB16 is an idea choice for illuminating factories, warehouses, gymna-siums, and other outdoor areas.







Features & Benefits:

  • Durable die-cast aluminum housing and polycarbonate lens.
  • Advanced aesthetic design with a screw-free optical lens for a clean and uncluttered look.
  • Offer 2 selectable CCT (40K/50K), with the option for 3 selectable CCT (30K/40K/50K)
  • Three adjustable Wattage levels available for each models.
  • Optics Adjustable (70°/90°/110°)
  • 0-10V dimming driver standard for 10% to 100% dimming
  • 6KV surge protection.
  • Operating temperature is -40°C to 55°C.产品认证图标_HB14 HB16

Product Detail

Download

Product Tags

Specification
Series No.
MHB16
Voltage
120-277V, 120-347V, 277-480V
Dimmable
0-10V dimming
CCT
3000K/4000K/5000K
Beam Angle 70°, 90°, 110°
Wattage
150W, 200W,  250W
Light Output
Max 41000lm
Operating Temperature
-40°C to 55°C
Lifespan
50,000 hours
Warranty
5 year
Application
Warehouses, Industrial, Retail
Mounting
Hanging Ring Mount,Conduit Pendant Mount,U-Bracket Mount
Accessory
Emergency Battery, Plug-in PIR sensor, U-Bracket
Dimensions
150W
Ø12.3 in x 6.26 in
200W Ø14.18 in x 6.28 in
250W Ø15.5 in x 6.4in

  • LED High Bay Light Specification Sheet
